Tecpro PS751 Intercom Power supply

The Tecpro PS751 is a free-standing, single-circuit Series 2 intercom power supply, ideal for schools and smaller venues where simplicity of operation is essential. It provides 24V DC to power small to medium sized intercom systems, terminating audio lines with the correct impedance for full-duplex (simultaneous two-way) conversations over extended cable runs.

Housed in a tough extruded aluminium case built to withstand the rigours of the live events environment. Fully compatible with older Tecpro designs. Canford Audio part number: 27-751.

Features

• Free-standing, compact design
• Tough extruded aluminium case
• Universal power supply — operates worldwide without resetting
• Short circuit and overload protection with automatic reset
• Powers up to 45 x BP511 or 50 x BP111 beltpacks
• 4 x XLR4F intercom ring output sockets (3-pin XLR compatible with standard mic cables)
• Power ON and Overload LED indicators
• Compatible with previous generation Tecpro designs

Technical Specification

Power input	Universal 90–264V AC, 47–63Hz (IEC connector, cable supplied)
Power output	24V DC, 2A maximum
Output connectors	3-pin XLR male
Comms line	200 ohm audio, 5k ohm DC
Dimensions	215 × 110 × 47 mm
Weight	0.72 kg
Canford part number	27-751
